Input: 3-channel input, maximum gain+20dBu
Output: 6-channel output, maximum gain+20dBu
Output impedance: 600 Ω
Dynamic range: >108dBu, frequency response 22Hz-22KHz
Frequency response: <± 0.25dBu, 15Hz-20KHz
Intermodulation distortion: <0.01%, 20Hz-20KHz @+10dBu balance input
Sampling rate: 96KHZ
Signal to noise ratio: >100dBu, 20Hz-20KHz
Analog to digital/digital to converter: 24 bit input and output
Low pass/high pass filter: 12.18.24 or 48dB/octave
Parameter equalizer: Band width from 0.05 to 3 octaves, frequency from 20Hz to 20KHz, gain ± 20dB step 0.1dB
Delay: 0-2000ms
Delay step: 21us
Main menu key: parameter menu exit enter input A.B mute, edit and output channel control
LCD screen: 2 × 20 Led screen
Enter LED: 0. - 6. - 12. - 18. - 24. and limit
Output LED: 0. - 6. - 12. - 18. - 24. and limit
Product size HWD (mm): 45×483×240
Power supply: 50/60Hz, 90V-240V AC power<20W
Net weight/gross weight (kg): 2.8/3.5
